2025 Program

SWTest Asia has SOLD OUT!

We have reached our maximum registration capacity and all deadlines have passed. We can no longer accept new registrations or substitutions. No on-site registrations will be accepted.

定員に達しましたので受付を終了させていただきました。心より感謝申し上げます。
現地会場での参加登録はお受けできませんのでご了承ください。

The 2025 program will be updated with more details in August 2025.

Last updated:

Schedule-At-A-Glance

subject to change

For details on the schedule for the 5th Annual Golf Tournament on Saturday, November 22, please visit the golf webpage.

Attendee Registration Check-In will be from 8:00 to 17:00 on both Thursday and Friday.

Thursday, November 20
Friday, November 21

Detailed Technical Session Schedule

Wednesday, November 19
TimeEvent
20:00 – 23:00EXPO Move-In/Setup
Thursday, November 20
TimeEvent
7:30 – 9:30EXPO Move-In/Setup
7:30 – 17:00Conference Registration Check-In
8:45 – 9:15Welcome to SWTest Asia 2025
Jerry BROZ, PhD (SWTest Conference General Chair – USA)
9:15 – 10:00THURSDAY VISIONARY KEYNOTE (more details)
Leading edge test technology and strategy for Automotive products
Kazuyuki IWAGURO
Vice President of HPC Business management and Operations Division (Renesas Electronics Corporation – Japan)
10:00 – 10:30Tea Break in EXPO Hall
10:00 – 17:30SWTest Asia 2025 EXPO Open
10:30 – 12:00Technical Session 1: Enabling HBM Test
Session Chair: Eric Chia-Cheng CHANG (Intel – USA)
10:30 – 11:00The emergence of Advanced Memories and its impact on Probe test solutions.
Alistair LAING (Micron Technology – USA)
11:00 – 11:30Innovations in Testing for Truly Known Good High Bandwidth Memory Stacks
Alan LIAO (FormFactor – USA), Hiromitsu TAKASU (Advantest – Japan)
11:30 – 12:00Evaluation of Probing Parameters via Post-Probe Micro Bump Pattern Analysis
Tsung Yi CHEN (MPI Corporation – Taiwan)
12:00 – 14:00LUNCH in EXPO Hall
12:25 – 12:45Tech Showcase 1 – MPI Corporation
Title: TBD
13:25 – 13:45Tech Showcase 2 – Micronics Japan Co., Ltd.
Title: TBD
14:00 – 15:30Technical Session 2: Probe Potpourri
Session Chair: Masahide OZAWA (Micronics Japan Co. – Japan)
14:00 – 14:30How AI can reduce cost and extend the lifetime of probe cards
Nunzio RENZELLA (Advantest – Italy)
14:30 – 15:00Inrush Current Suppression Technology for Probe Needle Protection
Kenichi TAKANO (Keysight Technologies – Japan)
15:00 – 15:30Innovative Cleaning Wafer Strategies to Enhance Memory Probing Efficiency
Victoria TRAN (Gel-Pak – USA), Keiichi RYU, Miki NOMURA, Tomonao NAKASHIMA (JEM – Japan)
15:30 – 16:00Tea Break in EXPO Hall
15:30 – 16:00Technical Poster Session
15:35 – 15:55Tech Showcase 3 – Form Factor
Title: TBD
16:00 – 17:30Technical Session 3: Materials Challenges
Session Chair: Patrick MUI (JEM America – USA)
16:00 – 16:30New probes for wafer test at highest current densities
Georg FRANZ (T.I.P.S. Messtechnik GmbH – Austria)
16:30 – 17:00Combining Material Development & Advanced Processing into High-Quality Foils to optimize application performance and cut costs
Martin SENZEL, Matthias WEGNER, Nail AKROUTI (Heraeus Precious Metals – Germany)
17:00 – 17:30Development of a High-Hardness Pd Alloy “TK-SK” with Hardness over 600 HV for Pogo Pin Applications
Keisuke ODAKURA, Kunihiro SHIMA, Takeshi FUSE, Takeyuki SAGAE (TANAKA PRECIOUS METAL TECHNOLOGIES Co., Ltd. – Japan)
17:30 – 20:00Kagamiwari Ceremony & Welcome Reception

Poster Session

Session Chair: Nyi Nyi THEIN (Western Digital Corporation – Japan)

  • Evaluation of Palladium Alloy Probe with Suppressed Sn Diffusion Reaction
    Kenichi SATO, Tomohisa HOSHINO, Naohito ODANI (Yokowo Corporation – Japan), Shohji IKUO (Graduate School of Science and Technology, Gunma University – Japan)
  • Technologies to support data transmission with extremely high frequencies (400G+) on printed circuit boards
    Quaid Joher FURNITUREWALA (Advantest America Inc – USA)
  • High Voltage DUT Power Supply IC for Automotive Grade Testing
    Thomas ABIOG (Elevate Semiconductor – USA)
  • A Modern Low Current, Low Leakage Switch Matrix
    Hai DAU, Israel ECHEVARRIA, John WILLIAMSON, Christine BUI (Spire Manufacturing, Inc. – USA)
  • A POGO-Type MEMS pin for Fine-Pitch Probing
    Jong-Uk BU, Ho-Sub BANG, Hwangsub KOO, SangHyeop LEE, Seo KOO, Seokhwan YOO, Youngho NAM (WithMEMS – South Korea)
  • Probe Card Analyzer Motherboard Flexibility and Performance Improvement
    Stefan THURMAIER (Turbodynamics GmbH – Germany)
  • Applying Chiplet Concepts to Interfaces: Breaking the Barriers Holding the Industry Down
    Eric SHOEMAKER, Brian BRECHT (DIS Tech – USA)
  • Innovative Testing Strategies for Silicon Photonic Devices in Engineering and Production Applications
    Dan RISHAVY, Kainoa KEKAHUNA (FormFactor – USA)
  • Evaluation of Ultra-High-Multi Layer PCB (124L) for Probe Card
    Yasuyuki SHINBO, Toshihiko OGURA (OKI Circuit Technology Co., Ltd. – Japan)
  • Enlarging the scope of process monitoring based cost reduction in probing operations
    Martin KUNZ (Solarius GmbH – Germany), Franz STEGER (Texas Instruments – Germany)
  • High Pin Count, High Parallelism Vertical Probe Card Characterization Strategies for HVM Automotive Bump Wafer Testing
    Cameron HARKER (FormFactor – USA), Yoichi URAKAWA (FormFactor – Japan)
  • Reinventing Guide Plates for Vertical Probe Cards: Solving Design Constraints with Advanced Laser Drilling and Materials Science
    Chris STOKES (Oxford Lasers – United Kingdom)
  • From Concept to Extended Validation: Localized Thermal Management for AI and GPU Wafer Testing
    Klaudiusz HOLECZEK (Watttron GmbH – Germany), Klemens REITINGER (ERS electronic GmbH – Germany)
  • New Re-Shaping Sheet for probe with High Processing and Long-Life Span
    Tad ROKKAKU (Probe Innovation USA, LLC – USA)
  • Development of low CTE LTCC material for ST substrates
    Yasuo YAMAZAKI, Eiichi NAKAMURA, Shigekatsu KONO, Takahisa YAMAGUCHI (Nippon Electric Glass Co., Ltd. – Japan)
Friday, November 21
TimeEvent
7:30 – 17:00Conference Registration Check-In
8:45 – 9:00Friday Program Overview
Jerry BROZ, PhD (SWTest Conference General Chair – USA)
9:00 – 10:00FRIDAY VISIONARY KEYNOTE (more details)
Rapidus Initiatives and Logic Testing Challenges in Advanced Semiconductor Manufacturing
Atsuhiko OHNO
Distinguished Engineer
Technology Department #5 (Wafer/Package Test), Engineering Center (Rapidus Corporation – Japan)
10:00 – 10:30Tea Break in EXPO Hall
10:00 – 10:30Technical Poster Session
10:00 – 16:00EXPO Open
10:30 – 12:00Technical Session 4: Photonics
Session Chair: Alan FERGUSON (Oxford Lasers – UK)
10:30 – 11:00Photonic Wafer-Level Testing in the Era of AI
Roman ZVAHELSKYI, Andres MACHADO, Florian RUPP, Philipp-Immanuel DIETRICH (Keystone Photonics – Germany)
11:00 – 11:30Silicon Photonics Production Wafer Testing by Utilizing Advantest V93000 SOC ATE platform
Hsu Hao CHANG, Andrew YICK, Calvin YANG, Supreet KHANAPET (Marvell – USA), Christian KARRAS, Gregor KUPKA, Tobias GNAUSCH (Jenoptik – Germany), Derek WU, Jeff JHERN, Natan CHEJANOVSKY, Shiyang DENG (Advantest – USA), Kengo SUZUKI (Advantest – Japan)
11:30 – 12:00A Compact OTA Measurement System with a Lens-Equipped Anechoic Chamber for Antenna-in-Package Modules
Yasushi SHIRAKATA, Kenichi MITSUGI, Shoichi KOSHIKAWA, Tomohisa HOSHINO (Yokowo Co., Ltd. – Japan)
12:00 – 14:00LUNCH in EXPO Hall
12:25 – 12:45Tech Showcase 4 – Heraeus Precious Metals GmbH & Co. KG
Title: TBD
13:25 – 13:45Tech Showcase 5 – Japan Electronic Materials Corporation
Title: TBD
14:00 – 15:30Technical Session 5: Optical Challenges
Session Chair: Muru MEYYAPPAN (Lattice Semiconductors – USA)
14:00 – 14:30New Method for Mounting Lens Module on Probe Card for CMOS Image Sensors testing
Tomonao NAKASHIMA (Japan Electronic Material Corp – Japan), Hiroki TSUTSUMI (INTER ACTION Corporation – Japan)
14:30 – 15:00Opto-electronic probe card with single-mode fiber array for wafer-level PIC testing
Takaharu OHYAMA, Tomohisa HOSHINO, Yasushi WATANABE, Yui NIIJIMA (YOKOWO CO., LTD. – Japan)
15:00 – 15:30Eclipse Dynamic Probe Card: A Novel Approach for Wafer-Level Photonic Testing with Automated Fiber Array Unit Alignment
Alessia GALLI (Technoprobe – Italy), Andrew YICK, Calvin YANG, Hsu Hao CHANG (Marvell – US)
15:30 – 16:00Tea Break in EXPO Hall
15:30 – 16:00Technical Poster Session
16:00 – 17:30EXPO Move-Out
16:00 – 17:30Technical Session 6: Advance PCB Design
Session Chair: Nobuhiro KAWAMATA (FormFactor – Japan)
16:00 – 16:30Multi-site Testing at Wafer Sort for Power Devices
Aseem SRIVASTAVA, Tom TRAN (Teradyne, Inc – USA)
16:30 – 17:00Evaluating PWB Power supply characteristics of Stacked vs Single Copper Configurations
Wai Kit K (Lincstech Co., Ltd. – Japan)
17:00 – 17:30Breaking Boundaries: Over 160 Layers, 10mmt Main PCB Redefining High-Density Interconnect
Sohei YASUDA (FICT Limited – Japan)
17:30 – 17:35SWTest Asia 2025 Technical Awards
17:35 – 20:00Japanese Street Food Festival

Poster Session

Session Chair: Nyi Nyi THEIN (Western Digital Corporation – Japan)

  • Evaluation of Palladium Alloy Probe with Suppressed Sn Diffusion Reaction
    Kenichi SATO, Tomohisa HOSHINO, Naohito ODANI (Yokowo Corporation – Japan), Shohji IKUO (Graduate School of Science and Technology, Gunma University – Japan)
  • Technologies to support data transmission with extremely high frequencies (400G+) on printed circuit boards
    Quaid Joher FURNITUREWALA (Advantest America Inc – USA)
  • High Voltage DUT Power Supply IC for Automotive Grade Testing
    Thomas ABIOG (Elevate Semiconductor – USA)
  • A Modern Low Current, Low Leakage Switch Matrix
    Hai DAU, Israel ECHEVARRIA, John WILLIAMSON, Christine BUI (Spire Manufacturing, Inc. – USA)
  • A POGO-Type MEMS pin for Fine-Pitch Probing
    Jong-Uk BU, Ho-Sub BANG, Hwangsub KOO, SangHyeop LEE, Seo KOO, Seokhwan YOO, Youngho NAM (WithMEMS – South Korea)
  • Probe Card Analyzer Motherboard Flexibility and Performance Improvement
    Stefan THURMAIER (Turbodynamics GmbH – Germany)
  • Applying Chiplet Concepts to Interfaces: Breaking the Barriers Holding the Industry Down
    Eric SHOEMAKER, Brian BRECHT (DIS Tech – USA)
  • Innovative Testing Strategies for Silicon Photonic Devices in Engineering and Production Applications
    Dan RISHAVY, Kainoa KEKAHUNA (FormFactor – USA)
  • Evaluation of Ultra-High-Multi Layer PCB (124L) for Probe Card
    Yasuyuki SHINBO, Toshihiko OGURA (OKI Circuit Technology Co., Ltd. – Japan)
  • Enlarging the scope of process monitoring based cost reduction in probing operations
    Martin KUNZ (Solarius GmbH – Germany), Franz STEGER (Texas Instruments – Germany)
  • High Pin Count, High Parallelism Vertical Probe Card Characterization Strategies for HVM Automotive Bump Wafer Testing
    Cameron HARKER (FormFactor – USA), Yoichi URAKAWA (FormFactor – Japan)
  • Reinventing Guide Plates for Vertical Probe Cards: Solving Design Constraints with Advanced Laser Drilling and Materials Science
    Chris STOKES (Oxford Lasers – United Kingdom)
  • From Concept to Extended Validation: Localized Thermal Management for AI and GPU Wafer Testing
    Klaudiusz HOLECZEK (Watttron GmbH – Germany), Klemens REITINGER (ERS electronic GmbH – Germany)
  • New Re-Shaping Sheet for probe with High Processing and Long-Life Span
    Tad ROKKAKU (Probe Innovation USA, LLC – USA)
  • Development of low CTE LTCC material for ST substrates
    Yasuo YAMAZAKI, Eiichi NAKAMURA, Shigekatsu KONO, Takahisa YAMAGUCHI (Nippon Electric Glass Co., Ltd. – Japan)
